Technical data Red Dragon® X pump 50 Watt / 1.500 l/h air intake:
max. 50 Watt/h, adjustable 15-50 Watt
speed adjustable Brushless DC pump (24V Technology)
Intake side: Nozzle with ozone & air plug
Pressure side: reducing ring Ø 32 mm
Delivery rate: max. 1.500 l/h air-intake // max. 4.000 l/h water-intake
Operating voltage: 230 Volt 50 Hz (also in 110V/60Hz available) (24V Technology)
Protection class pump: IP 68 control unit: IP 66
Weight pump: 2,3 kg
Dimension pump: 110 mm wide / 190 mm length / ~ 150 mm height
Dimension control unit: 20 mm wide / 90 mm length / ~ 170 mm height
RDX Skimmer Pump – Operating_and_maintenance_manual.pdf
- Saltwater resistant M4 grade 2 titanium screws
- Saltwater resistant parabolic rubber feet for acoustic decoupling
- Extreme low noise brushless DC-delivery pump with external control electronics
- High efficient technology, Sine Wave for very quiet running
- Easy usage and maintenance, low risk of calcification
- compact design against vibrations and oscillation
- CE conformity, developed and built
- high quality touchscreen display with feeding function
(protection against dry-running, over heating, over voltage, blocking etc.) - included in the scope of delivery:
- Pump with 2m supply line
- Controller with 1,5m supply line
- Power plug with 1,5m supply line / rubber connector
- Nozzle with Air- and Ozone connection
- Manual German/English
Suitable for:
for Mini Bubble King 200 VS21
for Bubble King® Double Cone 180 + 200
for Bubble King® SuperMarin 200
for Bubble King® DeLuxe 200
Delivery with suitable connection piece
Silicone-decoupling-connection-pieces 25mm
Silicone-decoupling-connection-pieces 32mm
RDX Skimmer Pump – Operating_and_maintenance_manual.pdf
//////////////////////////////////////////////////////////////////////////////////////////////////////////////////
- Saltwater resistant M4 grade 2 titanium screws
- Saltwater resistant parabolic rubber feet for acoustic decoupling
- Extreme low noise brushless DC-delivery pump with external power electronics
- High efficient technology, Sine Wave for very quiet running
- Inlet and Outlet complete with DIN connection, compact dimensions
- Easy usage and maintenance, low risk of calcification
- compact design against vibrations and oscillation
- CE conformity, developed and built
- high quality touchscreen display with feeding function
(protection against dry-running, over heating, over voltage, blocking etc.) - included in the scope of delivery:
- Pump with 2m supply line
- Controller with 1,5m supply line
- Power plug with 1,5m supply line / rubber connector
- with inlet protection
- with 20mm socket and 25mm socket with O-rings
- Manual German/English
